941 - Silvent

AIR NOZZLE
SILVENT 941

Item number: 09410369441, 09410469443

Stainless steel mini-flat nozzle

SILVENT 941 is a small angled flat nozzle in stainless steel. The nozzle generates a wide thin air stream. Due to its small dimensions, the nozzle is very suitable for machine designs with limited space. The SILVENT 941 is also commonly used in small, silent and efficient custom made air knifes. The Silvent technology makes it possible to combine efficient and silent blowing.

Noise reduction 17 dB(A)

Energy savings 7.1 scfm

Technical data

Replace open pipe Ø (inch)5/32

Blowing force12.0 oz

Air consumption (scfm)10.6

Sound level (dB(A))78

Nozzle technologySlot

Material (nozzle)1.4404 (316L)

ConnectionNPT 1/8"

Connection typeMale

Weight (lbs)0.031

Max temp. (°F)752

Max op. pressure (psi)145

Benefits when replacing an open pipe

Replace open pipe Ø (inch)5/32

Noise reduction17 [dB(A)]69%

Energy savings7.1 [scfm]40%

Material specification: EN 1.4404

Blowing properties at different pressures

Pressure (psi)

406080100120

Blowing force (oz)

7.910.813.716.619.4

Air consumption (scfm)

7.79.711.613.615.5

Sound level (dB(A))

72.876.479.080.881.6

Blowing coverage (inch)

1.38

2.36

3.54

4.72

Technical specifications

See basic information about the technical data. Read more
