AIR NOZZLE
SILVENT 9015W

Item number: 9015W0169228, 9015W0269228

Flat nozzle (ZYTEL)

SILVENT 9015W: an energy-efficient flat nozzle that generates a strong, efficient blowing force at an exceptionally low noise level. Compressed air is optimally used in this flat nozzle, which through its unique design introduces a completely new blowing technology feature. The aerodynamic nozzle design achieves the effect by maximizing entrainment of air. Each orifice is also uniquely designed to optimize the entrainment area. The air nozzle – SILVENT 9015W – is made exclusively of Zytel, a high-performance material without which the unique and truly complex Laval orifices would not be possible. These small orifices combined with the aerodynamic slots of the nozzle provide high efficiency.

Noise reduction 29 dB(A)

Energy savings 181.3 scfm

Technical data

Replace open pipe Ø (inch)11/16

Blowing force9.9 lbs

Air consumption (scfm)134.2

Sound level (dB(A))94

Nozzle technologyLaval

Material (nozzle)ZYTEL

ConnectionNPT 1/2"

Connection typeMale

Weight (lbs)0.342

Max temp. (°F)356

Max op. pressure (psi)145

Benefits when replacing an open pipe

Replace open pipe Ø (inch)11/16

Noise reduction29 [dB(A)]87%

Energy savings181.3 [scfm]57%

Material specification: Zytel HTN FG52G35 HSL BK011, Desmopan 487, EN 10088-3

Blowing properties at different pressures

Pressure (psi)

406080100120

Blowing force (oz)

95.0135.0175.0215.0255.0

Air consumption (scfm)

90.0115.0140.0165.0190.0

Sound level (dB(A))

89.092.595.096.497.0

Blowing coverage (inch)

6.10

7.09

8.27

9.84
