703 - Silvent

AIR NOZZLE
SILVENT 703

Item number: 07030139083, 07030239083

Stainless steel slot nozzle

SILVENT 703: specially made entirely of stainless steel with aerodynamic slots to allow optimal utilization of compressed air while keeping the noise level to a minimum. The high ambient temperatures of a glass works, the extreme blowing forces used in a steel mill or the stringent hygienic requirements of the food processing industry are examples of typical areas of application. Blowing force approximately 3 times stronger than SILVENT 701 (9.6 N (2.1 lbs)). Part of SILVENT's 700 series, together with 701, 705, 710 and 720.

Noise reduction 16 dB(A)

Energy savings 20.6 scfm

Technical data

Replace open pipe Ø (inch)9/32

Blowing force2.1 lbs

Air consumption (scfm)33.5

Sound level (dB(A))89

Nozzle technologySlot

Material (nozzle)1.4305 (303)

ConnectionNPT 1/2"

Connection typeFemale

Weight (lbs)0.119

Max temp. (°F)752

Max op. pressure (psi)145

Benefits when replacing an open pipe

Replace open pipe Ø (inch)9/32

Noise reduction16 [dB(A)]67%

Energy savings20.6 [scfm]38%

Material specification: EN 1.4305

Blowing properties at different pressures

Pressure (psi)

406080100120

Blowing force (oz)

19.628.437.847.156.0

Air consumption (scfm)

21.129.538.047.154.8

Sound level (dB(A))

84.988.090.291.992.3

Blowing coverage (inch)

3.74

5.51

7.48

9.25
