AIR NOZZLE
SILVENT 2005
Item number: 20000169001, 20000269001
- Slot nozzle (aluminum)
SILVENT 2005: an aluminum nozzle with aerodynamic slots. Produces a strong, quiet and effective air stream. The blowing force is approximately 5 times that of SILVENT's 209 and 511 nozzles. Despite its powerful force, both the noise level and energy consumption are low in comparison with 10 mm (3/8") open pipe blowing.
Noise reduction 18 dB(A)
Energy savings 51.2 scfm
Technical data
Replace open pipe Ø (mm)10
Blowing force (N)14.5
Air consumption (Nm³/h)98
Sound level (dB(A))94
Nozzle technologySlot
Material (nozzle)Al
ConnectionG 3/8"
Connection typeMale
Weight (g)12
Max temp (°C)150
Max op. pressure (MPa)1.0
Benefits when replacing an open pipe
Replace open pipe Ø (mm)10
Noise reduction18 [dB(A)]71%
Energy savings87 [Nm³/h]47%
Material specification: EN AB 44300
Blowing properties at different pressures
Pressure (kPa)
2004006008001000
Blowing force (N)
6.612.217.823.429.0
Air consumption (Nm³/h)
48.581.1114.0146.8179.6
Sound level (dB(A))
82.890.094.497.499.3
Blowing coverage (mm)
82
108
162
215
50
100
200
300
Technical data
Replace open pipe Ø (inch)3/8
Blowing force3.2 lbs
Air consumption (scfm)57.7
Sound level (dB(A))94
Nozzle technologySlot
Material (nozzle)Al
ConnectionNPT 3/8"
Connection typeMale
Weight (lbs)0.026
Max temp. (°F)302
Max op. pressure (psi)145
Benefits when replacing an open pipe
Replace open pipe Ø (inch)3/8
Noise reduction18 [dB(A)]71%
Energy savings51.2 [scfm]47%
Material specification: EN AB 44300
Blowing properties at different pressures
Pressure (psi)
406080100120
Blowing force (oz)
31.245.058.872.686.5
Air consumption (scfm)
36.349.863.276.790.3
Sound level (dB(A))
86.390.593.595.897.7
Blowing coverage (inch)
3.23
4.25
6.38
8.46
2
4
8
12
Technical specifications
See basic information about the technical data. Read more
Instructions for use
Read Silvent Group General Instructions for Use before you install the product.
