306 L-S - Silvent

AIR KNIFE
SILVENT 306 L-S

Item number: 03060169157, 03060269157

Stainless steel air curtain

SILVENT 302 L-S - 306 L-S: is an air knife in stainless steel with 209 L-S nozzles. For applications that require a curtain of air across a broad surface. Typical areas of application include air cleaning, curtains around doors and entrances, paint drying, cleaning of conveyor belts, plywood sheets etc. Custom lengths are available upon request.

Noise reduction 27 dB(A)

Energy savings 48.9 scfm

Technical data

Blowing force4.5 lbs

Air consumption (scfm)60.0

Sound level (dB(A))85

Nozzle technologyLaval

Material (nozzle)1.4404 (316L)

ConnectionNPT 3/8"

Connection typeFemale

Weight (lbs)1.967

Max temp. (°F)752

Max op. pressure (psi)145

Benefits when replacing an open pipe

Replace open pipe Ø (inch)3/8

Noise reduction27 [dB(A)]85%

Energy savings48.9 [scfm]45%

Material specification: EN 1.4301, EN 1.4305, EN 1.4404

Blowing properties at different pressures

Pressure (psi)

406080100120

Blowing force (oz)

41.460.678.097.8120.0

Air consumption (scfm)

39.050.466.081.696.0

Sound level (dB(A))

80.383.685.989.492.1

Blowing coverage (inch)

11.42

12.40

14.37

16.34

Technical specifications

See basic information about the technical data. Read more
